• Qualified for Automotive Applications
• AECA-Q100 Qualified with the following results:
– Device temperature grade
–40°C to +140°C
– Device HBM classification level 2
– Device CDM classification level C6
• 5-V Turn-off Under Voltage Lockout (UVLO)
• Drives Two N-Channel MOSFETs in High-Side and Low-Side Configuration With Independent Inputs
• Maximum Boot Voltage 120-V DC
• 4-A Sink, 4-A Source Output Currents
• 0.9-Ω Pullup and Pulldown Resistance
• Input Pins Can Tolerate –10 V to +20 V and are Independent of Supply Voltage Range
• TTL Compatible Inputs
• 5-V to 17-V VDD Operating Range, (20-V ABS Maximum)
• 7.2-ns Rise and 5.5-ns Fall Time With 1000-pF Load
• Fast Propagation Delay Times (20-ns typical)
• 4-ns Typical Delay Matching • Available in the SOIC8(Powerpad) package
| roduct Attribute | Attribute Value |
| Gate Drivers |
| MOSFET Gate Drivers |
| High-Side, Low-Side |
| SMD/SMT |
| SO-PowerPad-8 |
| 2 Driver |
| 2 Output |
| 4 A |
| 5 V |
| 17 V |
| 7.2 ns |
| 5.5 ns |
| - 40 C |
| + 140 C |
| UCC27212A-Q1 |
| AEC-Q100 |
| Reel |
| Cut Tape |
| Development Kit: | UCC27212EVM-328 |
| Features: | AECA-Q100 qualified |
| Moisture Sensitive: | Yes |
| Operating Supply Current: | 2.5 mA |
| Product Type: | Gate Drivers |
| 2500 |
| Subcategory: | PMIC - Power Management ICs |
| Technology: | Si |
| Unit Weight: | 0.019048 oz |
